◆系統主要參數 Main technical parameters (請從上到下瀏覽訪問大有量真實案例相冊圖片提供下參考價值)
器機型號查詢 Model |
STR-9070/9080 |
STR-1010 |
的工作艙規格 Internal size(mm) |
900×800×650 |
1000×1000×790 |
該機厚度 Complete machine size(mm) |
900×1030×1750 |
1000×1540×1830 |
開關電源 Power |
220V 50Hz |
220V 50Hz |
產品照明系統燈 Machine floodlight |
一個60W隔爆燈 |
220V 13W節約能源燈 |
滾筒機承載的重量 Roller bearing |
10-30Kg |
10-30Kg |
分開器三相電機 Separator motor |
220V 50Hz 550W |
220V 50Hz 550W |
離心離心過濾器風口尺寸 Separator air volume |
8.5m3/min |
8.5m3/min |
壓縮成廢氣源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
機單重 Weight |
320kg |
380 kg |
◆貨品優勢 Product features
1. 設定創新、整潔畢節、空間結構小學科學、作業省事;
2. 定時開關化掌控定時開關化噴砂,配備定時開關噴砂,點動產品定位等功效;
3. 滾桶外徑及噴槍數目可結合加盟商使用需求方案制造;
4. 就可以了自行,又可自行,噴砂口感好,一機好用。
1.novel design, beautiful and easy, scientific structure, convenient operation
2.Automatic control automatic gush arenaceous, have the point start timing gush arenaceous, positioning, and other functions;
3.Roller diameter and spray gun quantity can be designed according to the customer demand;
4.Can manual and automatic, gush arenaceous well, multi-use.
◆適合條件 Applicable scope
適合于大批小部件的手工或自主噴砂,比如:電鐵質品、螺釘、工程塑料制
品、鈕扣、拉鏈頭、壓克力板、機器人零主件等;
Apply to lots of small the manual or automatic spray sand, for example: electric wood products, screw, plastic products, button, zipper, the force that press a gram, machine parts, etc.
